RJ45 network transformer role

RJ45 network transformer is mainly used for isolation and matching of Ethernet interface. It is a dual-port transformer with two independent circuits that can pass signals from one circuit to another while maintaining the strength and quality of the signal and isolating electrical noise and interference between circuits.
RJ45 network transformer is widely used in Ethernet interface, network switch, router, gateway, server, industrial automation equipment and other fields. It can help improve network transmission speed and stability, reduce electromagnetic interference and noise, and improve system performance and reliability.
The role of RJ45 network transformer includes the following aspects:
Signal isolation: RJ45 network transformer can pass signals from one circuit to another while isolating electrical noise and interference between circuits to prevent signal interference and loss.
Signal matching: RJ45 network transformer can match signals from one resistance value to another to ensure the best effect of signal transmission.
Electrical isolation: RJ45 network transformer can isolate two circuits to prevent problems such as electrical interference and electrical shock, and improve the reliability and stability of the circuit.
Power supply isolation: RJ45 network transformer can isolate the power supply to prevent noise and interference in the power supply.
In short, RJ45 network transformers are widely used in Ethernet interfaces, which can help improve signal transmission quality and reliability, reduce electromagnetic interference and noise, and improve system performance and stability.
